کیس رکمونت سوپر میکرو دوئال پاور (SUPERMICRO CSE-815TQC-R706CB)
- تضمین بهترین قیمت بازار
- پشتیبانی عالی ۲۴ ساعته، ۷ روز هفته
- بازگشت وجه در صورت عدم رضایت
- اصالت کالاها از برترین برندها
- تحویل سریع در کمترین زمان ممکن
موجود
: ویژگی های محصول
1U Chassis for motherboard support size: (12" x 13") 4 x 3.5" hot-swap SAS/SATA SAS or enterprise SATA HDD only recommended 1U 4-Port 12Gbps Backplane Support 4x3.5 1U Redundant 700/750W Single Output Power Supply Platinum level, 54.5mm width 1 full-height & full-length expansion slot(s) 4 x 40x56mm counter-rotation PWM fan(s)
Standard Parts List | |||
Part Number | Qty | Description | |
Air Shroud | MCP-310-19002-0N | 1 | SC815/113/116 Intel DP X9, X8 PC air shroud, 12x13MB |
HD Backplane | BPN-SAS3-815TQ | 1 | 1U 4-Port 12Gbps Backplane Support 4×3.5 |
Cable(S) | CBL-0071L | 1 | ROUND 16 TO 16 PIN RIBBON FP CABLE 30″L, LF |
Cable(S) | CBL-PWCD-0160-IS | 2 | PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,16AWG,RoHS/REACH |
CD-ROM & Accessory | CSE-PT93L-B | 1 | Black DVD dummy cover for SC813, 813M, 815, PBF-RoHS |
Fan(s) | FAN-0156L4 | 4 | 40x40x56 mm 13K-11K RPM Counter-rotating Fan,RoHS/REACH |
Front Panel | FPB-FP813-D | 1 | Front control board dual color for SC815,SC813M (C) |
Cooling Fan & Accessory | CSE-PT0135 | 1 | FAN HOLDER FOR SIX 40X56MM COUNTER ROTATING FANS |
Cooling Fan & Accessory | MCP-340-00035-0B | 2 | Dummy fan 40x56mm for 40×56 counter-rotating fan (cost-effective) |
Drive Tray(s) | MCP-220-00075-0B | 4 | Black gen 5.5 hot-swap 3.5″ HDD tray |
Power Distributor | PDB-PT112-2424 | 1 | SC112 24PIN REDUNDANT PWS DISTRIBUTOR |
Part(s) | MCP-260-00024-0N | 1 | 1U I/O shield for X8 server MB (3rd LAN + 4xLAN) |
Part(s) | MCP-260-00078-0N | 1 | 1U I/O shield for X10 and X9 Server MB with 5X5mm vent hole and EMI Gasket,RoHS/REACH,PBF |
Power Supply & Accessory | MCP-250-81502-0N | 1 | SC815 Redundant Power Distributor Cover |
Power Supply & Accessory | PWS-706P-1R | 2 | 1U 750W redundant power width 54.5mm(Platinum),HF,RoHS/REACH,PBF |
Mounting Rail(s) | MCP-290-00054-0N | 1set | Rail set, quick/quick, optional for 1U 17.2 |
Rear Window | MCP-240-00086-0N | 1 | STD rear window for SC113 redundant PWS |
